Grubee SkyHawk 4G T-Belt Drive V-Mount Kit, With HuaSheng 49cc Engine

Grubee SkyHawk 4G T-Belt Drive V-Mount Kit, With HuaSheng 49cc Engine

  • $ 34900

Add to wishlist

*** DISCONTINUED ***

Grubee SkyHawk 4G T-Belt Drive V-Mount Kit, With HuaSheng 49cc Engine



Fits HuaShang 49cc Cent. Clutch Engine only (Clutch is automatic). Transmission, Gas Tank, 415 Chain, Engine Mount, Throttle & Cable, Idler, 3-pcs. wide pedal crank fits big or small bottom hole, Clamp to spokes sprocket kit, 12T HD Freewheel drive sprocket, 100 T one-way gear (the old one way bearing has been eliminated), and 48T wheel sprocket. One way bearing eliminated. This top-of-the-line Grubee brand 49cc bike motor kit comes in a V-Frame mount. With this kit you'll be able to convert your bicycle into a gas-powered motorized bike. These 4G T-Belt can be installed on almost any mens bike, mountain bikes or beach cruiser. The V-Frame mount fits 26" beach cruiser bikes and most 20" to 26" mens bike. This 4G T-Belt Drive motor has the advantage of no oil contamination and no gear noise.



HuaSheng 4-Cycle 49cc Motor Specs:





  • No load RPM: 8500 Cooling: Forced Air
  • Displacement bore & stroke: 41.8 x 35.8
  • Power: 1.2KW @6800 rpm
  • Torque: 2.0Nm @4500 rpm
  • Engine net weight: 5.2 kg
  • Length x width x height: 247 mm x 225 mm x 335 mm
  • PTO shaft rotation: CCW centrifugal clutch
  • Crankcase oil change: 50 hours after change, first at 10 hours operation
  • Rear mount engine has closed loop fuel system. V-Frame mount does not



    The V-Frame Kit includes:





  • Belt Drive Transmission Engine
  • Gas Tank
  • 415 Chain
  • Engine Mount
  • Throttle & Cable
  • Idler
  • 3 pieces wide pedal crank fits big or small hole
  • 50T clamp to spokes sprocket





  • Free technical support within one (1) week after receiving the kit

  • Pay no sales tax (except CA) on this 4-stroke gas bike motor kit!

    _______________________________________________________________

    Bicycle Requirements:
    This bicycle motor engine kit fits most mens 24" and larger bicycles which includes mountain, cruiser, chopper and road bikes with a V-frame with at least a 8.5" height clearance for the engine. Larger frame size requires drilling into bike frame and use of the universal face plate. Dimensions: This 49cc bicycle motor engine kit is about 8.5" height 7" length 5" width and fits on most standard 24” – 26” or 25mm 29mm frame bicycle frame tubes. Larger frame size requires drilling into bike frame and use the universal face plate. This engine kit only adds about 20 lbs to your bike. Orders received Monday - Friday by 3:00PM EST are eligible for
    Same Day Shipping! Except for USPS which ships the next business day.


    We can ship to PO BOXES at this time. Through UPS we offer many shipping methods and for International and Canadian shipping we suggest UPS STANDARD, (2-6 days; does not cover Customs Brokerage, Duties, and Taxes… these are charged to the consignee on delivery). We have found that this is the cheapest way to send packages to Canada. Skills & Experience: The buyer may need some basic hardware skills, tools, and it takes roughly around 2-3 hours to install and to do some adjustments and fine tuning. Notices & Disclaimer:
  • We cannot guarantee that this kit will fit your specific individual bike(s).
  • Operating a bike, motorized bicycle or bike with a bicycle engine kit installed involves some risk of serious bodily injury. Buyer accepts responsibility for any and all vehicle operation that may lead to personal injury, economic loss, social distress, other losses, costs and damages.
  • Seller is not responsible for injuries and/or damages resulting from operating this motorized bicycle or bicycle engine kit.
  • Seller is not responsible for misuse of this kit or any warranty after installation.
  • Not all motorized bicycles are allowed for on road use.
  • We make no guarantee as to the road legality of these bike motors.

    * Orders received Monday - Friday by 3:00PM EST are eligible for
    Same Day Shipping! Except for USPS which ships the next business day.


    Same Day Shipping Available


    Only California shipped orders are charged sales tax

    Our gasoline operated products are NOT compliant with Environmental Protection Agency ( E.P.A. ) or California Air Resources Board (C.A.R.B) for the use on/off Public roads. Upon purchase, the buyer agrees to use products for racing (closed-course competition) only and NOT for on/off public roads.
